The Fuel EXe heralds Trek's first trail bike entry into the category of lightweight e-bikes. Ideally suited for anyone who wants the benefits of pedal assistance but prefers the looks and ride feel of an analogue bike. At only 19.05kg for the size medium, it's only 5.4kg heavier than its conventional counterpart. This low weight penalty is made possible with the use of a lightweight and low bulk drive system from TQ, housed in a carbon fibre frame. The TQ drive system is so quiet that the motor noise is hardly perceptible, especially when compared to high-powered e-bikes. Despite its small size, the motor still kicks out 250W and 50Nm of torque, for getting you to the top the quickly, so you can enjoy the descent with fresh legs.
The suspension platform is based on the standard Fuel EX with 150mm of travel up front and 140mm in the rear. This is delivered by the Fox Rhythm 36 fork and Fox Performance Float X shock respectively. The drivetrain is from Shimano's ever-dependable SLX groupset, with the exception of the rear derailleur, which sees an upgrade to XT. The gearing is 1x12 speed with a monstrous 10-51 cassette in the rear for all the range you will ever need. The SRAM Code R brakes leave nothing to be desired in the way of stopping power. Excellent for keeping your speed in check on steep descents.
The frame geometry is bang up-to-date for snappy handling and stability at speed so you can deathgrip through rock gardens with confidence. Trek's active braking pivot suspension design ensures that you get the full benefit of your rear suspension's shock absorption, even under heavy braking load.
If you want an electric mountain bike that balances uphill power with trail bike handling, then look no further than the Fuel EXe 9.7.
Product Code: BIFSH4AL0115
OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chainline, Mino Link, ABP, Boost148, UDH, 140 mm travel | |
Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 150 mm travel | |
FoPerformance Float X, 2-position damper, 205 mm x 60 mm | |
E*thirteen E*spec Plus, 34T, 165 mm length | |
Shimano XT M8100, long cage | |
Shimano SLX M7100, 12-speed | |
Shimano SLX M7100, 10-51, 12-speed | |
Shimano SLX M7100, 12-speed | |
SRAM Code R 4-piston hydraulic disc | |
F: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle / R: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle | |
Bontrager Line Comp 30, Tubeless Ready, 28-hole, Presta valve | |
Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 29x2.50" | |
Bontrager Line, alloy, 35 mm, 27.5 mm rise, 780 mm width | |
Bontrager Elite, 35 mm, 0-degree, 45 mm length | |
Bontrager XR Trail Elite, nylon lock-on | |
TranzX JD-YSP39, internal routing, 34.9 mm | |
Bontrager Arvada, austenite rails, 138 mm width | |
TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power | |
TQ 360 Wh | |
TQ handlebar-mounted|TQ LED display with Bluetooth & ANT+ connectivity | |
M - 19.05 kg |
Please note, electric bikes cannot be shipped to home addresses. They must be collected from an Alpine Bikes or Tiso Outdoor Experience (OE) store. Please select click and collect as the delivery option at the checkout and choose your desired store to collect from. The bike will be sent to the store, built and inspected. A member of staff will then contact you to let you know your bike is ready for collection. Any other items on the order will also got to the store to be collected with the bike.
Size | Rider Height | Inseam |
---|---|---|
S | 153 - 167 cm | 72 - 79 cm |
5'0" - 5'6" | 28" - 31" | |
M | 161 - 175 cm | 76 - 82 cm |
5'3" - 5'9" | 30" - 32" | |
L | 174 - 188 cm | 82 - 88 cm |
5'9" - 6'2" | 32" - 35" | |
XL | 186 - 196 cm | 87 - 92 cm |
6'1" - 6'5" | 34" - 36" |
Use our slider to choose your deposit between 10% to 50% (max deposit subject to basket/product value)
This item can be returned by post or to your nearest Tiso Group store – for more details see our Returns Policy.
Price | Model Year | Frame | Fork | Rear Shock | Crank | Rear Deraileur | Front Deraileur | Shifters | Casette | Chain | Bottom Bracket | Breakset | Wheels | Hubs | Rims | Tyres | Handlebars | Stem | Grips | Headset | Seat Post | Saddle | Pedals | Motor | Battery | Controller | Weight | |
Trek Fuel EXe 9.7 - 2023 - Galactic Grey / Black View Now |
£7,020.00 £7,800.00 | 2023 | OCLV Mountain Carbon, removable battery, internal routing, alloy rocker link, 34.9 mm seat tube, upper chain guide mount, 55 mm chainline, Mino Link, ABP, Boost148, UDH, 140 mm travel | Fox Rhythm 36, Float EVOL air spring, GRIP damper, tapered steerer, 44 mm offset, Boost110, 15 mm Kabolt axle, 150 mm travel | FoPerformance Float X, 2-position damper, 205 mm x 60 mm | E*thirteen E*spec Plus, 34T, 165 mm length | Shimano XT M8100, long cage | Shimano SLX M7100, 12-speed | Shimano SLX M7100, 10-51, 12-speed | Shimano SLX M7100, 12-speed | SRAM Code R 4-piston hydraulic disc | F: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle / R: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle | Bontrager Line Comp 30, Tubeless Ready, 28-hole, Presta valve | Bontrager XR5 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 60 tpi, 29x2.50" | Bontrager Line, alloy, 35 mm, 27.5 mm rise, 780 mm width | Bontrager Elite, 35 mm, 0-degree, 45 mm length | Bontrager XR Trail Elite, nylon lock-on | TranzX JD-YSP39, internal routing, 34.9 mm | Bontrager Arvada, austenite rails, 138 mm width | TQ-HPR50, 50 Nm, 250 watt maximum continuous rated power, 300 watt peak power | TQ 360 Wh | TQ handlebar-mounted|TQ LED display with Bluetooth & ANT+ connectivity | M - 19.05 kg | |||||
Trek Rail 9.8 XT - 2023 - Trek Black / Marigold to Red View Now |
£7,495.00 £8,349.00 | 2023 | NEW OCLV Mountain Carbon main frame, 1.8" lower head tube, Removable Integrated Battery (RIB), Knock Block 2.0, guided internal routing, 34.9 mm seat tube, magnesium rocker link, Motor Armour, Mino Link, ABP, Boost148, 12 mm thru axle, 150 mm travel | RockShox ZEB Select+, DebonAir spring, Charger 2.1 RC damper, eMTB optimised crown, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 160 mm travel | RockShox Super Deluxe Ultimate RT3, DebonAir spring, Thru Shaft 3-position damper, 230 mm x 57.5 mm | E*thirteen E*spec Plus, 34T, 165 mm length | Shimano XT M8100, long cage | Shimano XT M8100, 12-speed | Shimano XT M8100, 10-51, 12-speed | Shimano XT M8100, 12-speed | Shimano XT M8120 4-piston hydraulic disc | F: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle / R: Bontrager alloy, sealed bearing, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12 mm thru axle | Bontrager Line Comp 30, Tubeless Ready, 28-hole, Presta valve | Bontrager SE5/6 Team Issue, Tubeless Ready, Core Strength sidewalls, aramid bead, 120 tpi, 29x2.50" | Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width | Bontrager Line Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 45 mm length | Bontrager XR Trail Elite, nylon lock-on | Integrated: FSA Headset Bearing, MR122 / 229 | Bontrager Line Elite Dropper, MaxFlow, internal routing, 34.9 mm | Bontrager Arvada, austenite rails, 138 mm width | Bosch Performance Line CX, smart system, magnesium motor body, 85 Nm, 20 mph or 32 km/h max assist (25 km/h max assist in EU and APAC) | Bosch PowerTube 750 Wh, smart system | Bosch Kiox 300, smart system w/ remote | M - 23.40 kg |
