Description
Cruise through your commute or along city streets on a weekend adventure with Scott’s Passage 20 Wave Hybrid E-Bike. Designed with a strong alloy frame in a full step-through construction, the Passage 20 Wave suits a range of riders, short to tall, for a comfortable ride that’s also adjustable through the handlebars so you can tailor the bike to your preferred comfort level and riding style.
At the centre of this commuting cruiser is the Bosch Performance Line SX motor, paired with an integrated CompactTube 400Wh battery for an effortless performance at the pedals whilst maintaining a natural feel, 55Nm of torque and a favourable Q factor. Positioned low in frame and weighing in at just 2kg, the Bosch motor is a reliable favourite, supplying range that’ll get you where you need to go.
Handily featuring an SR Suntour suspension fork with 75mm of travel to smooth out cobbles and unavoidable potholes, the Passage 20 also has 45mm tyres for added stability, a Shimano CUES 9-speed drivetrain for reliable shifting and Shimano disc brakes for smooth, efficient and safe stopping power. Equipped with accessories to enhance your leisure or commuting experiences, this bike comes with front and rear lights, fenders, a kickstand and the Racktime Micro rear rack, engineered to support two 8kg side bags so you can load up with shopping, a gym duffel or your work bag. Touring the town or weaving your way to the office on the commute, the Passage 20 Wave from Scott is geared up and kitted out with everything you need for a smooth, powerful and reliable cycling experience.
Features:
- Bosch Performance Line SX with 400 Wh battery: 55Nm of torque, the lightest drive unit in the Bosch range - compact, sporty and paired with the integrated 400Wh CompactTube battery
- Motor unit is just 2kg, low in the frame and compact enough to provide confidence and a more natural pedalling style thanks to its favourable Q factor
- Adjustable stem: allows you to raise or lower the handlebar to improve comfort, make you body and ride style
- Design rear rack: Racktime Micro rear rack supports 8kg + 8kg side bags integrated with fenders and a Supernova rear light, and is Snap It 2.0 compatible
- Step-through frame: open design makes it easy to mount and dismount for riders of all sizes
- SR Suntour 75mm suspension fork to soften rough pavements
- 45mm tyres add stability and durability no matter what comes your way
- Shimano CUES 9-speed drivetrain gives a gearing range to ride around like a pro
- Passage eRIDE alloy frame
- Shimano disc brakes for smooth, efficent and safe stopping power
- Lezyne Fusion front light / Supernova integrated rear lights
- Weight: 22.2kg / 48.94lbs
-
Max. system weight: 130kg (overall weight includes the bike, the rider, the equipment, and possible additional luggage)
Accessories:
- Front light: Lezyne Fusion E550SM
- Rear light: Rear Supernova TL3Z
- Rack: Racktime Micro Rack SnapIt 2.0 8KG
- Fenders: Alumee alloy profile
- Kickstand: Passage Kickstand
Notice:
- Please note: Scott state that bike specifications are subject to change without prior notice.
Specifications
Specifications
| Battery Type | Compact Tube 400Wh | Charger: 2A charger |
| Brake Set | Shimano BR-MT200 Disc | Rotor: Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm |
| Cassette | Shimano LG300, 11-46T |
| Chain | Shimano LG500 | Chainring: FSA 38T | Chainguide: Syncros |
| Crank | FSA CK-220 170mm |
| Electric Assisted Speed Limit | 15.5 MPH / 25 KPH |
| Electric Bike | Yes |
| Fork | SR Suntour NRX32-E Air LO R, Tapered , 15x100 bolt Axle, Remote Lock Out , Steel Steerer, 75mm Travel |
| Frame | Alloy S-L=29", 6061 Alloy custom butted tubing | Top extraction battery |
| Frame Material | Aluminium | Alloy |
| Handlebars | Alloy Handle Bar, Rise 12mm, Backsweep 15°, 680mm wide |
| Headset | Acros, 1.5"- 1.5" semi integ. OD 50/61mm, ID 44/55mm |
| Hubs | FRONT: Shimano HBTC50015B CL, 15x100mm | REAR: Shimano FHTC500HMB CL, 12x142mm |
| Motor | Bosch Performance Line SX (BDU314Y) EU: 25kmh | Display: Bosch Purion 200 |
| Pedals | Marwi SP-827 |
| Rear Derailleur | Shimano CUES RDU4000GS 9 Speed |
| Rims | Syncros X15 Disc |
| Saddle | Syncros Capilano |
| Seatpost | Syncros M3.0, 31.6 |
| Shifters | Shimano CUES SLU4009RC, 9 Speed |
| Stem | Adjustable stem 90mm 10°-60 |
| Suspension Type | Front Suspension |
| Tyres | FRONT: Schwalbe G-One Overland 365 Performance, 700x45C | REAR: Schwalbe G-One Overland 365 Performance, 700x45C |
| Wheels | Spokes: Black Spokes |
| Wheel Size | 700 |
