Description
New to the trails or looking for a rugged commuter that’ll also double as a trail mountain bike? The Trek Marlin 5 Gen 3 Mountain Bike is right where you need to start – packed with features to get you off the beaten track and into new territories. Adapted for each size, the lightweight aluminium frame will accommodate smaller riders with a curved top tube and lower standover height, paired with Smart Wheel Sizing that ensure you’re shredding with the fastest wheel that fits, shorter reach brake levers and narrower handlebars so however small the rider, they maintain effortless confidence and control.
Trek have updated the 9-speed Shimano CUES drivetrain with LINKGLIDE technology to increase the lifespan on wear-prone components such as the chain, cassette and chainrings so this workhorse just keeps on going. Whether on the trail or riding on the tarmac, the Marlin 5’s hydraulic disc brakes will make sure you’ve got efficient stopping power whatever the conditions, and a suspension fork with travel up to 100mm will help smooth out the terrain ahead of you. If you’re planning to be out for most of the day, rear kickstand mounts, rack mounts and the Bontrager Blendr stem tech where you can clip gear directly to the stem, means you’ve got plenty of options for keeping supplies with you for the long haul.
Gear up and get out on the bike whether you are dipping your toe in MTB adventures, looking for a beast to cruise you through the commute or simply wanting to snap up a deal, the Marlin 5 Gen 3 has plenty to offer without breaking the bank.
Features:
- Marlin models in size XS curved top tube and lower standover height that makes it easier for smaller riders
- Smart Wheel Size ensures you're on the fastest wheel that fits and smallest sizes comes with short reach brake levers and narrower handlebars to give smaller riders better comfort and more control
- Stylish frame with internal shift cable and brake hose routing for less maintenance and a sleeker look
- 9-speed Shimano CUES: LINKGLIDE drivetrain technology for significantly increased life on wear items like chain, cassette and chainrings
- Trail-savvy aluminium frame with up to 100mm of travel in the suspension fork
- Mounts for a rack and kickstand make it ideal for trail riders, or anyone looking for a comfortable, stable commuter
- Weight (size M): 15.10kg / 33.29lbs
- Please note: Trek reserve the right to make changes to the product information and specifications provided and due to supply chain issues, compatible parts may be substituted at any time without notice
Specifications
Specifications
| Chain | Shimano LG500 |
| Crank | Shimano CUES U4001, 32T, 52mm chain line | Size XS, S, M, ML: 170mm length | L, XL, XXL: 175mm length |
| Fork | SR Suntour XCT 30, coil spring, preload, hydraulic lockout | Size XS: 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel | Size S: 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel | Size M, ML, L, XL, XXL: 42 mm offset for 29" wheel, 100 mm QR, 100 mm travel |
| Frame | Size XS: Alpha Silver Aluminium, curved top tube, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew | Size S, M, ML, L, XL, XXL: Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew |
| Frame Material | Aluminium |
| Grips | Trek Line Comp, nylon lock-on |
| Handlebars | Bontrager alloy, 31.8 mm | Size XS: 5mm rise, 690mm width | Size S: 15mm rise, 720mm width | Size M, ML, L, XL, XXL: 15mm rise, 750mm width |
| Headset | Semi-integrated, 1-1/8" |
| Hubs | FRONT: Formula DC-20, alloy, 6-bolt, 5x100 mm QR | Front skewer: Trek Thru-Skew | REAR: Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR | Rear skewer: 173x5 mm QR |
| Pedals | VP-536 nylon platform |
| Rims | Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve |
| Saddle | Bontrager Verse Short, stainless steel rails |
| Shifters | Shimano U4000, 9-speed |
| Stem | Size XS, S: Bontrager Comp, 31.8 mm, 7-degree, 35 mm length || Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree - Size M, ML, L: 50mm length; Size XL: 60mm length; Size XXL: 70mm length |
| Tyres | Size XS, S: Bontrager Montrose comp, wire bead, 30 tpi 27.5"x2.40" | Size M, ML, L, XL, XXL: Bontrager Montrose comp, wire bead, 30 tpi, 29"x2.40" |
| Wheels | Spokes: 14 g stainless steel, black |
