The Rail is a long-travel electric mountain bike built for fast descents and gnarly terrain. It features the same high-end trail tech and character as analogue Trek bikes, just supercharged. Think of the Rail as a Slash/Remedy hybrid with a built-in shuttle. The Bosch drive unit will have you doing three times your normal lap at the local trail centre and, as we all know, more riding = more fun.
On the Rail 5 Deore, the robust alloy frame delivers 150mm of rear suspension travel and holds a 625 Wh battery for long days lapping the trails or adventuring in the mountains. A 160 mm RockShox RockShox 35 Gold RL suspension fork and Tektro 4-piston hydraulic brakes keep you in control when descending. The powerful Bosch Performance Line CX (250 W, 85 Nm) motor and smooth-shifting 1x10 Shimano Deore drivetrain will get you to the top of the hill in record time. The electric assist works at speeds up to 25 km/h and a neat handlebar remote allows you to cycle through the different assistance modes. All of the Bosch electronics are part of their new Smart System that allows you to update and customise your bike from the Bosch app. You can use it for activity tracking, diagnostics and range calculation too.
This bike is ready for big mountain terrain, so if you want to ride further and harder, you want a Trek Rail.
Product Code: BIFSH4AL0121
| Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, magnesium rocker link, Motor Armour, Mino Link, ABP, Boost148, 12 mm thru axle, 150 mm travel | |
| RockShox 35 Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 44 mm offset, oversized crown for eMTB, Boost110, 15 mm Maxle Stealth, 160 mm travel | |
| RockShox Deluxe Select+ RT, 230 mm x 57.5 mm | |
| E*thirteen E*spec Plus, 165 mm length | |
| Shimano Deore M6100, long cage | |
| Shimano Deore M6100, 12-speed | |
| Shimano Deore M6100 | |
| Tektro HD-M745 4-piston hydraulic disc | |
| Front: Bontrager sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle | |
| Alex MD35, tubeless compatible, 32-hole, 35 mm width, Presta valve | |
| Bontrager XR4 Comp, wire bead, 30 tpi, 29x2.60" | |
| Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width | |
| Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 50 mm length | |
| Bontrager XR Trail Comp, nylon lock-on | |
| TranzX JD-YSP18, internal routing, 31.6 mm | |
| Bontrager Arvada, steel rails, 138 mm width | |
| Rear: Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12 mm thru axle | |
| Bosch PowerTube 625Wh, smart system | |
| Bosch handlebar remote | |
| M - 24.88 kg |
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | 153.0 - 166.5cm | 161.0 - 175.0cm | 174.0 - 188.0cm | 186.0 - 196.0cm |
| 5'0.2 - 5'5.6 | 5'3.4 - 5'8.9 | 5'8.5 - 6'2.0 | 6'1.2 - 6.5.2 | |
| Inseam | 72 - 79 cm | 76 - 82cm | 82 - 88cm | 87 - 92cm |
| 28.3" - 31.1" | 29.9" - 31.9" | 32.3" - 34.6" | 32.3" - 36.2" |
